CL801-D-06

This m/c is strong tensile force & high speed cord knitting m/c.

It is moved by belt, no oil inside, just need a little space for the m/c.

The m/c is noiseless and can be fed directly from bobbins or cones.

The products can be used in shoelace, Elastic cord, trimmings, flat cord, ropes...etc.

No special maintenance is required.











Specification
M/C N.W.
400 kgs


CREEL N.W.
150 kgs


M/C G.W.
450 kgs


CREEL G.W.
250 kgs


M/C size
125x80x170 /cm by wooden case


Creel size
285x74x26 /cm by wooden case


Option Device
Creel for 200 bobbin (Special size)
1 set


Finish product collector
1 set


Yarn tensioner
2 sets


Elastic yarn feeding roller
1 set


Yarn collecting equipment
1 set


Technical Data
Cylinder
6 (CK-06)
10 (CK-10)
6 (CKD-06)


Gauge
3,4,6,8,10,12,16
3,4,6,8,10,12
3,4,6,8,10,12,16


Speed
800~1500 rpm


Standard Equipment
ITEM UNIT



Motor (1.5HP)
1 pcs


Automatic stop device
1 set


Inverter
1 set


Latch needle
200 pcs


Dropper
200 pcs


Tool
1 set


Diameter
1mm~12mm









We reserve the right to modify the specification and design of machine without prior notice.
The above data is for reference only, other terma set on meeting.
